AMG M157 5.5L BiTurbo Intake Spacer Kit – E63, CLS63, S63, CL63, SL63

AMG M157 5.5L BiTurbo Intake Spacer Kit – E63, CLS63, S63, CL63, SL63

Regular price $150.00 USD
Regular price Sale price $150.00 USD
Sale Sold out
Shipping calculated at checkout.

Let your 5.5L AMG V8 breathe the way it should. This CNC-machined Intake Filter Spacer Kit for the M157 (5.5L BiTurbo AMG) removes a known restriction inside the factory airbox—improving airflow efficiency, sharpening throttle response, and increasing midrange punch without changing the look of your engine bay.

🔥 Key Features for M157 AMG Platforms

  • Optimized airflow at the filter seal: Spacer geometry reduces the choke point at the airbox lid, increasing effective inlet area and smoothing turbulence.
  • Works with OEM & performance filters: Fully compatible with factory paper elements and all high-flow performance filters.
  • OEM engine cover friendly: Retains factory fitment and maintains a stock-clean appearance—ideal for sleeper builds.
  • CNC-machined aluminum construction: Strong, heat-stable, corrosion-resistant, and precision-fit for all M157 airboxes.
  • Optional Cerakote finish: Stealth black or custom colorways with engraving available.

📈 Real-World Performance Benefits

  • Faster turbo response: Reduced restriction lets the twin turbos spool sooner and with less effort.
  • Smoother, more immediate throttle feel: Consistent airflow improves drivability in both Comfort and Sport modes.
  • More headroom for tuned cars: Eliminates an upper-airbox bottleneck that becomes a limiting factor on tuned M157 setups.
  • Perfect stealth mod: Completely hidden inside the airbox—no visible modifications even during inspections.

No tune required — fully compatible with stock ECU mapping.

🔬 Why the Spacer Works

The M157 airbox creates a pressure drop where the filter seals against the lid. At higher airflow levels—especially on tuned or aggressively driven cars—this becomes a significant restriction. Raising the filter into the optimal flow path increases effective inlet area, reduces turbulence, and improves compressor efficiency. The result: smoother airflow, quicker response, and more consistent performance under load.

✔️ Compatibility – M157 5.5L BiTurbo AMG

Fits all Mercedes-Benz models equipped with the M157 5.5L BiTurbo V8 engine:

Model Trim Years
S-Class (W221) S 63 AMG 2011–2013
S-Class (W222) S 63 AMG 2013–2017
CL-Class CL 63 AMG 2011–2014
CLS-Class CLS 63 / CLS 63 S AMG 2012–2018
ML-Class ML 63 AMG 2012–2015
GLE-Class GLE 63 / GLE 63 S AMG 2015–2019
GL-Class GL 63 AMG 2012–2016
GLS-Class GLS 63 AMG 2016–2019
G-Class G 63 AMG 2013–2018
E-Class E 63 / E 63 S AMG 2012–2016
SL-Class SL 63 AMG 2012–2019

📦 What’s Included

  • (2) CNC-machined aluminum intake spacers (left + right), 4 interlocking pieces each
  • Extra screws and rubber washers

🧰 Installation

Around 20–30 minutes. Run through these steps once for each air filter housing.

Tool Required Torx T-25 driver
Spacer Pieces 4 aluminum pieces per air filter housing
Hardware Extra screws and rubber washers included
  1. Lift the front engine cover off. Tug the sides to free the side clips, then lift the front to release the front clips. It pulls straight up off its rubber mounts.
  2. Release the duct and the sensor. Each air filter housing has a worm-gear clamp where the intake duct meets it, and a sensor connector. Loosen the clamp, work the duct off, then unclip the connector.
  3. Lift the housing out and turn it upside down. That exposes the factory Torx screws. Unscrew them with the T-25 driver.
  4. Slot the four aluminum pieces together. They interlock at the corners. Press each corner together until the frame sits square.
  5. Fit a rubber washer at every screw point. One per screw hole, linking both halves of the housing.
  6. Run the screws through. Each screw goes through the original housing screw hole, down through its washer, and out the other side.
  7. Tighten evenly. Work across the housing rather than round it, like wheel bolts. Snug is enough.
  8. Refit the housing. Drop it back into place, push the duct on and tighten its clamp, then click the sensor connector home. Give the connector a gentle tug to confirm it's latched.
  9. Refit the engine cover. Line it up and push down directly above each clip until it seats. Don't press in the middle and hope.

See this kit fitted — customer build on Instagram →

🏁 Why Trust BenzUnited Performance Parts?

For over 12 years, we’ve been testing, tuning, and daily-driving high-performance Mercedes-Benz and AMG platforms. Every part we design is based on real-world testing—not theory, not hype.

  • We build parts for the platforms we own: W212/W213 E-Class, W218 CLS, W222 S-Class, R231 SL, W166/W292 SUVs, and more.
  • No gimmicks: If a part doesn’t make a measurable improvement on our own AMGs, we don’t sell it.
  • Maximum value, maximum gains: We target hidden airflow and heat bottlenecks that deliver real acceleration and response gains.
  • OEM-plus philosophy: Clean installs, no reliability tradeoffs, no tuning hacks—just real performance.

When you buy from BenzUnited, you’re getting parts engineered, tested, and validated in-house by enthusiasts who know these cars inside and out.

BenzUnited Performance Engineering — Proven AMG Upgrades. Real Results.
